The Special Square 160702 is a Siegmund table press accessory used as an extension and vertical fixation of the System 16 Table Press. It measures 195 x 60 x 60 mm and weighs 1.41 kg. BTH Sales is the exclusive Canadian importer of Siegmund.
Specifications
| Item no. | 160702 (siegmund.com) |
|---|---|
| Siegmund name | Special Square System 16 |
| System | Siegmund System 16 (Ø16 mm bores, 50 mm grid) |
| Length | 195 mm (7.68 in) |
| Width | 60 mm (2.36 in) |
| Height | 60 mm (2.36 in) |
| Weight | 1.41 kg (3.11 lb) |
- Siegmund also includes 160702 in the table press Basic-Set 160783, together with the thrust pieces 000701.PA and 000701.AL.
Works with this product
Compatibility
- Fits: Siegmund System 16 welding tables and tooling with Ø16 mm bores.
- Not compatible: System 28 (Ø28 mm) tables; Siegmund builds each system around one bore size.
- Related products: 160780 Siegmund System 16 - Table Press, 000701.AL Siegmund System 16/28 - Thrust Piece.
- Care & grounding: anti-spatter spray, CleanBasic cleaner, Ground Connection Comfort (S16/S28).
What's included
- 1 x Siegmund Special Square System 16 (160702)
Typical uses
- Extending the System 16 table press
- Fixing the press vertically on the table
Engineering support & demos
Engineering support comes with your purchase: fixture design, layout drawings, CAD and 3D models, site visits and cobot cell planning, handled by Travis Hardcastle at BTH Sales or by Siegmund directly. Live demos at our St. Marys showroom are by appointment (book a demo), and we offer video demos if you are outside Ontario. BTH Sales is family-owned, founded in 2001, and has been the exclusive Canadian importer of Siegmund since 2018.
Industries served: Siegmund's published practical examples show its welding tables and tooling in these sectors: Agriculture; Interior; Lighting and electrical engineering; Machine tools and plant construction; Measurement and testing technology; Motorcycle engineering; Revolving door systems; Robotic technology; Stage technology; Stainless steel processing; Steel, sheet metal and metal construction; Textile production; Train Construction; Vehicle construction; Welding technology; Woodworking.
Ships across Canada by freight from 5 Industrial Rd, St. Marys, ON N4X 1G2, or pick up from our warehouse. Email sales@bthsales.ca or call +1-519-461-1381 for a freight quote and delivery estimate.
Frequently Asked Questions
What is the Special Square used for?
Siegmund lists it as an extension and vertical fixation of the table press.
Which press does it fit?
160702 is the System 16 version for the System 16 Table Press 160780. The System 28 press uses the Special Square 280702.
