Siegmund System 28 Stops

Siegmund System 28 stops position workpieces against a fixed or adjustable edge on a 28 mm welding table: eccentric stops for fine adjustment in tight spaces, universal stops with boreholes or an elongated hole, flex stops for corners and freeform edges, flat squares, and the angle alignment template with its spacer sleeve.

These System 28 parts also fit other 28 mm system welding tables with Ø28 mm bores on a 100 mm grid. Exclusive Canadian importer of Siegmund. Ships across Canada from St. Marys, ON.

Compare System 28 stops

Manufacturer data from siegmund.com. Size = length × width × material thickness. Suffix .N = nitrided, .C = chromed, .A = aluminium.
Product Item numbers Size (mm) Adjustment (per Siegmund)
Eccentric Stops 280401.N, 280402.N (M10 thread), 280403.N Ø 60 / Ø 100, 25 thick Infinite adjustment by twisting; for restricted space
Universal Stop 100 280407.N, 280407.C 100 × 50 × 25 Boreholes only, 50 mm apart
Universal Stop 150 280408.N, 280408.C 150 × 50 × 25 Boreholes only, 50 mm apart
Universal Stop 250 280409.N, 280409.C 250 × 50 × 25 Boreholes only, 50 mm apart
Universal Stop 150L 280410.N, 280410.A, 280410.C 150 × 50 × 25 Elongated hole 0–100 mm
Universal Stop 225L 280420.N, 280420.A, 280420.C 225 × 50 × 25 Boreholes + elongated hole 0–100 mm; also used with prisms and adapters
Universal Stop 225L FDS 280421 225 × 50 × 25 Elongated hole 0–100 mm plus spring-loaded part; for serial production
Universal Stop 300 280426.N, 280426.C 300 × 50 × 25 Triple boreholes + elongated hole 0–100 mm
Universal Stop 325L 280422.N 325 × 50 × 25 Boreholes + elongated hole 0–100 mm
Universal Stop 525L 280424.N, 280424.C 525 × 50 × 25 Boreholes + elongated hole 0–100 mm
Universal Stop 500S 280430.N, 280430.C 500 × 100 × 25 Boreholes + elongated hole 0–200 mm; for large components
Universal Stop 750S 280432.N, 280432.C 750 × 100 × 25 Boreholes + elongated hole 0–200 mm; for large components
Universal Stop 1000S 280434.N, 280434.C 1000 × 100 × 25 Boreholes + elongated hole 0–200 mm; for large components
Flat Square 175 280445, 280445.C 175 × 175, height 50 Borehole + elongated hole, adjustable up to 100 mm
Flat Square 500 280444 500 × 375, height 100 Borehole + elongated hole, adjustable up to 200 mm
Flex Stop 25x156 Aluminum 280412 156 × 52 × 25 Elongated hole, 100 mm range; favoured for stainless steel and confined spaces
Flex Stop 25x140 Steel 280416 140 × 40 × 25 Elongated hole, 100 mm range; rounded clamping surfaces for corners
Angle Alignment Template 280455.N 250 × 250 × 5 10° steps or continuous 0–90°, 1° scale; includes 2 spacer sleeves
Spacer Sleeve 280538 Ø 35, height 20 Height compensation when clamping the angle alignment template with bolts

Looking for the Clamp Stop (280760)? Siegmund files it under Prisms & Supports, so it is in Siegmund System 28 Prisms & Supports.

Related collections

Frequently Asked Questions

What is the difference between the Universal Stop 100, 150L and 500S?

Siegmund makes the Universal Stop 100, 150 and 250 with boreholes only, spaced 50 mm apart, for a fixed position. The L versions (150L, 225L, 325L, 525L) combine system boreholes with an elongated hole adjustable over 0–100 mm. The S versions (500S, 750S, 1000S) are 100 mm wide with a 0–200 mm elongated hole and are designed for stops and positioning of large components.

When should I use an eccentric stop or a flex stop?

Siegmund says eccentric stops (280401.N, Ø 60 mm) give infinite adjustment by simply twisting them and are used where space is restricted. Flex stops adjust through their elongated hole and have rounded clamping surfaces for corners and free-shaped stop surfaces; the aluminum Flex Stop 25x156 (280412) is favoured when working with stainless steel and in confined spaces.

What does the FDS on the Universal Stop 225L FDS mean for setups?

The Universal Stop 225L FDS (280421) has an additional spring-loaded part. Siegmund says this makes it suitable for clamping metal and molded components, with no additional fixation needed if no major welding deformation is expected. Its elongated hole adjusts 0–100 mm, and Siegmund names serial production as the typical application.

Why does the angle alignment template need spacer sleeves?

The Angle Alignment Template (280455.N) sets angles in 10° increments or continuously from 0–90° with a 1° scale, and it ships with 2 spacer sleeves. Siegmund says the Spacer Sleeve (280538) is required as height compensation when clamping the template with bolts.

Orders ship promptly once confirmed, and we'll send tracking when it leaves.

Regular price from $47.00 CAD
Sale price from $47.00 CAD
Regular price
Unit price
per
Items 280401.N, 280402.N and 280403.N: Siegmund Eccentric Stops, nitrided, for System 28 welding tables: Ø60 mm, Ø60 mm with M10 thread, and Ø100 mm. They adjust elements infinitely by simply twist...
Regular price from $54.00 CAD
Sale price from $54.00 CAD
Regular price
Unit price
per
Items 280407.N and 280407.C: Siegmund Universal Stop 100, nitrided or chromed, for System 28 welding tables with Ø28 mm bores. It is fixed firmly through its system bores, spaced 50 mm apart, with ...
Regular price from $68.00 CAD
Sale price from $68.00 CAD
Regular price
Unit price
per
Items 280408.N and 280408.C: Siegmund Universal Stop 150, nitrided or chromed, for System 28 welding tables with Ø28 mm bores. It is fixed firmly through its system bores, spaced 50 mm apart, with ...
Regular price from $99.00 CAD
Sale price from $99.00 CAD
Regular price
Unit price
per
Items 280409.N and 280409.C: Siegmund Universal Stop 250, nitrided or chromed, for System 28 welding tables with Ø28 mm bores. It is fixed firmly through its system bores, spaced 50 mm apart, with ...
Regular price $126.00 CAD
Sale price $126.00 CAD
Regular price
Unit price
per
Items 280420.N, 280420.C and 280420.A: Siegmund Universal Stop 225 L, nitrided, chromed or aluminum, for System 28 welding tables with Ø28 mm bores. Combining an elongated hole (0–100 mm range) wit...
Regular price from $83.00 CAD
Sale price from $83.00 CAD
Regular price
Unit price
per
Items 280410.N, 280410.A and 280410.C: Siegmund Universal Stop 150 L, nitrided, aluminum or chromed, for System 28 welding tables with Ø28 mm bores. Its elongated hole gives a precise 0–100 mm adju...
Regular price $126.00 CAD
Sale price $126.00 CAD
Regular price
Unit price
per
Item 280421: Siegmund Universal Stop 225 L FDS, burnished, with a spring pressure part, for System 28 welding tables. Siegmund says the spring suits clamping metal and molded components, so no extr...
Regular price $131.00 CAD
Sale price $131.00 CAD
Regular price
Unit price
per
Item 280422.N: Siegmund Universal Stop 325 L, nitrided, for System 28 welding tables with Ø28 mm bores. It combines system bores with an elongated hole (0–100 mm range), so it can be fixed firmly o...
Regular price from $162.00 CAD
Sale price from $162.00 CAD
Regular price
Unit price
per
Items 280424.N and 280424.C: Siegmund Universal Stop 525 L, nitrided or chromed, for System 28 welding tables with Ø28 mm bores. System bores plus an elongated hole (0–100 mm range) provide fixed a...
Regular price from $126.00 CAD
Sale price from $126.00 CAD
Regular price
Unit price
per
Items 280426.N and 280426.C: Siegmund Universal Stop 300, nitrided or chromed, for System 28 welding tables. Siegmund says it extends the stop surface, and its triple system bores plus an elongated...
Regular price from $223.00 CAD
Sale price from $223.00 CAD
Regular price
Unit price
per
Items 280432.N and 280432.C: Siegmund Universal Stop 750 S, nitrided or chromed, for System 28 welding tables. Siegmund designed it for stopping and positioning large components; system bores plus ...
Regular price from $252.00 CAD
Sale price from $252.00 CAD
Regular price
Unit price
per
Items 280434.N and 280434.C: Siegmund Universal Stop 1000 S, nitrided or chromed, for System 28 welding tables. Siegmund designed it for stopping and positioning large components; system bores plus...
Regular price from $176.00 CAD
Sale price from $176.00 CAD
Regular price
Unit price
per
Items 280430.N and 280430.C: Siegmund Universal Stop 500 S, nitrided or chromed, for System 28 welding tables. Siegmund designed it for stopping and positioning large components; system bores plus ...
Regular price $446.00 CAD
Sale price $446.00 CAD
Regular price
Unit price
per
The Flat Square 500 can be fixed firmly or adjusted variably because it combines system bores with an elongated hole. Siegmund says it adjusts freely over up to 200 mm. It is 500 x 375 x 100 mm, 25...
Regular price from $178.00 CAD
Sale price from $178.00 CAD
Regular price
Unit price
per
SIEGMUND SYSTEM 28 - FLAT SQUARE 175 The Siegmund System 28 Stops - Flat Square Accessories are compatible with any 28mm fixture table. Made in Germany to the highest of quality assurance, you kno...
