Siegmund System 16 - Universal Stop 150L

SKU: 2-160422.N

Siegmund System 16 - Universal Stop 150L

BTH Sales
$97.00
$97.00
Sale Sold out
/
Shipping calculated at checkout.
This is a pre order item. We will ship it when it comes in stock.

SIEGMUND SYSTEM 16 - UNIVERSAL STOP 150L



Siegmund system 16 Accessories are compatible with any 16mm fixture table. Made in Germany to the highest of quality assurance, you know that with Siegmund tooling, you will not be let down.

Universal Stops, fixed or variably adjustable, due to the combination of oblong slot and system boreholes. It is also appropriate for use with prisms and adapters.

Chromed version is available for work on measuring tables, working with aluminum and for TIG-welding.



Technical Data:

Item No.: 2-160422.N

Universal Stop 150 L ‐ nitrided

Length (a) 150 mm
Width (b) 35 mm
Material thickness (d) 12 mm
Weight 0,33 kg
Adjusting range 50 mm



Product description
Universal Stop 150 L, enables fixed and versatile adjustment (0-50 mm range), due to the combination of the elongated hole and system boreholes. It is also suitable for work with prisms and adapters.

‐ combination of borehole and elongated hole
‐ Standard with fine scaling on both sides
