The Vario Prism supports round pipes and 45° turned square pipes up to 80 mm in diameter thanks to its 90° and 120° angles. This burnished version has no collar and Siegmund says it can be fastened with bolts. BTH Sales is the exclusive Canadian importer of Siegmund.
Specifications
| Item no. | 160641 (siegmund.com) |
|---|---|
| Siegmund name | Vario Prism Ø 50 90°/120° without collar burnished |
| System | Siegmund System 16 (Ø16 mm bores, 50 mm grid) |
| Height | 35 mm (1.38 in) |
| Diameter | 50 mm (1.97 in) |
| Weight | 0.39 kg (0.86 lb) |
Works with this product
Compatibility
- Fits: Siegmund System 16 welding tables and tooling with Ø16 mm bores.
- Not compatible: System 28 (Ø28 mm) tables; Siegmund builds each system around one bore size.
- Related products: 160511 Siegmund System 16 - Fast Clamping Bolt Without Slot, 160649.1 Siegmund System 16 - Prism Extension.
- Care & grounding: anti-spatter spray, CleanBasic cleaner, Ground Connection Comfort (S16/S28).
What's included
- 1 x Siegmund Vario Prism Ø 50 90°/120° without collar burnished (160641)
Typical uses
- Supporting round pipe on a System 16 table
- Holding square tube turned at 45°
Engineering support & demos
Engineering support comes with your purchase: fixture design, layout drawings, CAD and 3D models, site visits and cobot cell planning, handled by Travis Hardcastle at BTH Sales or by Siegmund directly. Live demos at our St. Marys showroom are by appointment (book a demo), and we offer video demos if you are outside Ontario. BTH Sales is family-owned, founded in 2001, and has been the exclusive Canadian importer of Siegmund since 2018.
Industries served: Siegmund's published practical examples show its welding tables and tooling in these sectors: Agriculture; Interior; Lighting and electrical engineering; Machine tools and plant construction; Measurement and testing technology; Motorcycle engineering; Revolving door systems; Robotic technology; Stage technology; Stainless steel processing; Steel, sheet metal and metal construction; Textile production; Train Construction; Vehicle construction; Welding technology; Woodworking.
Ships across Canada by freight from 5 Industrial Rd, St. Marys, ON N4X 1G2, or pick up from our warehouse. Email sales@bthsales.ca or call +1-519-461-1381 for a freight quote and delivery estimate.
Frequently Asked Questions
What pipe sizes does the Vario Prism Ø50 take?
Siegmund says it suits both round and 45° twisted square pipes with a diameter up to 80 mm, thanks to its 90° and 120° angles.
How is the version without collar fixed?
Siegmund says this prism can be fastened with bolts. It can be used with all 16 mm boreholes.
