SKU: 2-280390.3.P

Siegmund System 28 - Square U-Shape 2000x400x400

Vendor BTH Sales
Regular price $8,224.00
Sale price $8,224.00 Regular price
Sale Sold out
Unit price
/per
Shipping calculated at checkout.
This is a pre order item. We will ship it when it comes in stock.

SIEGMUND SYSTEM 28 - SQUARE U-SHAPE 2000x400x400



The Siegmund System 28 Square U-Shapes - 400/200 are compatible with any 28mm fixture table. Made in Germany to the highest of quality assurance, you know that with Siegmund tooling, you will not be let down.

Square U-Shape 400/400 (sides 400 mm), for working with superstructures and heavy work pieces. Riser Blocks are firmly screwed by using connector bolts (Item No. 280560.N).

When used as a table extension exceeding 1000 mm, the Riser Block
has to be supported by a table leg. Combined with the legs (Item No. 280371), Riser Blocks can be flexibly used on the foundation rails.

A multitude of clamping- and connection options, using different Riser Blocks and Stops, are facilitated by the five-sided boreholes and the optional diagonal hole arrangement.

The 100x100 mm grid simplifies orientation. Diagonal grid upon request.



Technical Data:

Item No.: 2-280390.3.P

Square U-Shape 2000x400x400 Plasma nitrided

Length (a) 2000 mm
Width (b) 400 mm
Height (c) 400 mm
Material thickness (d) 25 mm
Weight  533 kg



Product description
Square U-Shape 400x400 (sides 400 mm), for working with superstructures and heavy work pieces. Riser Blocks are firmly screwed by using connector bolts (Item No. 280560.N).

When used as a table extension exceeding 1000 mm, the Riser Block
has to be supported by a table leg.

Combined with the legs (Item No. 280371), Riser Blocks can be flexibly used on the foundation rails.

A multitude of clamping- and connection options, using different Riser Blocks and Stops, are facilitated by the five-sided boreholes and the optional diagonal hole arrangement.

The 100x100 mm grid simplifies orientation.

From a length of 500 mm all U-shaped squares have mounting holes on the back to attach table legs (except 280310.P).
