SIEGMUND SYSTEM 28 - SQUARE U-SHAPE 200x200x200
The Siegmund System 28 Square U-Shape - 200/200 is compatible with any 28mm fixture table. Made in Germany with the highest quality assurance, you know that with Siegmund tooling, you will not be let down.
Square U-Shape 200/200 (sides 200 mm), ideally suited as a table extension, for vertical setups, as well as a sturdy connection between two welding tables. Riser Blocks are mounted to the table using connector bolts (Item No. 280560.N).
When used as a table extension exceeding 1000 mm, the Riser Block has to be supported by a table leg.
Combined with the legs (Item No. 280376), Riser Blocks can be flexibly used on the foundation rails.
A multitude of clamping- and combination options with other squares and stops are facilitated by the five-sided boreholes and the optional diagonal hole arrangement. The 100x100 mm grid simplifies orientation.
Technical Data:
|
Item No.: 2-280396.1.P Square U-Shape 200x200x200 Plasma nitrided
