Siegmund System 28 - Square U-Shape 500x200x100

SKU: 2-280310.P

Siegmund System 28 - Square U-Shape 500x200x100

BTH Sales
$925.00
$925.00
Sale Sold out
/
Shipping calculated at checkout.
This is a pre order item. We will ship it when it comes in stock.

SIEGMUND SYSTEM 28 - SQUARE U-SHAPE 500x200x100



Siegmund System 28 Square U -Shapes are compatible with any 28mm fixture table. Made in Germany with the highest quality assurance, you know that with Siegmund tooling, you will not be let down.

Square U-Shape 200/100 (sides 100 mm), ideally suited as a table extension for vertical setups, as well as a sturdy connection between two welding tables. The Square is firmly mounted to the table using Connecting Bolts (Item No. 280560.N).

If the Square is used as a table extension exceeding 1,000 mm, it has to be supported by a table leg.

The diagonal hole arrangement enables many clamping- and combination options in connection with other squares and stops. The 100x100 mm grid simplifies orientation.


Technical Data:

Item No.: 2-280310.P

Square U-Shape 500x200x100 Plasma nitrided

Length (a) 500 mm
Width (b) 200 mm
Height (c) 100 mm
Material thickness (d) 25 mm
Weight  31 kg



Product description
Square U-Shape 200x100 (sides 100 mm), ideally suited as a table extension for vertical setups, as well as a sturdy connection between two welding tables. The Square is firmly mounted to the table using Connecting Bolts (Item No. 280560.N).

If the Square is used as a table extension exceeding 1,000 mm, it has to be supported by a table leg.

The diagonal hole arrangement enables many clamping- and combination options in connection with other squares and stops.

The 100x100 mm grid simplifies orientation.

‐ with diagonal grid
