SIEGMUND SYSTEM 28 - SQUARE U-SHAPE 500x400x400
The Siegmund System 28 Square U-Shapes - 400/200 are compatible with any 28mm fixture table. Made in Germany to the highest of quality assurance, you know that with Siegmund tooling, you will not be let down.
Square U-Shape 400/400 (sides 400 mm), for working with superstructures and heavy work pieces. Riser Blocks are firmly screwed by using connector bolts (Item No. 280560.N).
When used as a table extension exceeding 1000 mm, the Riser Block
has to be supported by a table leg. Combined with the legs (Item No. 280371), Riser Blocks can be flexibly used on the foundation rails.
A multitude of clamping- and connection options, using different Riser Blocks and Stops, are facilitated by the five-sided boreholes and the optional diagonal hole arrangement.
The 100x100 mm grid simplifies orientation. Diagonal grid upon request.
Technical Data:
|
Item No.: 2-280360.3.P Square U-Shape 500x400x400 Plasma nitrided
