Siegmund Tooling, Clamps & Accessories

364 products
Burnished nitrided professional screw clamp – heavy-duty adjustable welding clamp with reinforced 20×10 mm horizontal and 20×13 mm vertical bars

BTH Sales is the exclusive Canadian importer of Siegmund. The Siegmund line we carry covers Professional Extreme 8.7 and 8.8 PLUS welding tables, welding plates, workbenches, clamps, stops, squares, bolts and tooling sets for System 16 and System 28.

Siegmund (Bernd Siegmund GmbH, Oberottmarshausen, Germany) defines each system by the borehole size of the table, and Siegmund says the choice depends on the type and size of your workpieces.

System 16 or System 28?

  • System 16 uses Ø16 mm boreholes on a 50 x 50 mm grid. Siegmund especially recommends System 16 for fine-detail fabrication and describes it as ideal for light to medium-duty work and precision fixtures.
  • System 28 uses Ø28 mm boreholes in a diagonal grid or a 100 x 100 mm grid. Siegmund describes System 28 as ideal for light to heavy components, designed for maximum clamping forces, multi-ton structures and high distortion forces.

Professional Extreme 8.7 tables use through-hardened X8.7 tool steel with plasma nitriding. The System 28 Professional Extreme 8.8 PLUS tables have 300 mm table sides; the 8.7 tables have 200 mm sides.

Shop Siegmund by category

For sizing help, read What size welding table do I need? and How to choose a welding table clamp.

Frequently Asked Questions

Can I use System 16 tooling on a System 28 table?

Not directly. Siegmund says all tool parts and sets can be used on all table series within one system. To work across systems, Siegmund offers connecting elements.

How much weight can a Siegmund welding table hold?

Siegmund rates load per table leg, as a static load: max. 1,000 kg (2,205 lb) per leg for System 16 basic legs, max. 2,000 kg (4,409 lb) per leg for System 28 basic legs and max. 3,000 kg (6,614 lb) per leg for System 28 PLUS legs. The leg type is listed on each table page.

Can I see a Siegmund table before I buy?

Yes. BTH Sales offers free, live Siegmund demonstrations by appointment in St. Marys, ON. Book through the demonstration page.

Free, live Siegmund demonstrations are available by appointment: book a demonstration.

Ships across Canada from St. Marys, ON. Contact sales@bthsales.ca or 519-461-1381.

Siegmund - System 16 Professional Extreme 8.7 - 1000x1000x100 Plasma nitrided ‐ table side with diagonal grid Steel Legs for Welding table top with holes
from $4,034.00 CAD
from $4,034.00 CAD
Item 160010.X7D: Siegmund System 16 Professional Extreme 8.7 welding table, 1000 x 1000 mm, with Ø16 mm bores on a 50 x 50 mm grid on the top and bored 100 mm sides. The top is through-hardened X8....
Siegmund - System 16 Professional Extreme 8.7 - 1200x1200x100 Plasma nitrided ‐ table side with diagonal grid Steel Legs for Welding table top with holes
from $5,292.00 CAD
from $5,292.00 CAD
Item 160015.X7D: Siegmund System 16 Professional Extreme 8.7 welding table, 1200 x 1200 mm, with Ø16 mm bores on a 50 x 50 mm grid on the top and bored 100 mm sides. The top is through-hardened X8....
Siegmund - System 16 Professional Extreme 8.7 - 2000x1000x100 Plasma nitrided ‐ table side with diagonal grid Steel Legs for Welding table top with holes
from $7,299.00 CAD
from $7,299.00 CAD
Item 160020.X7D: Siegmund System 16 Professional Extreme 8.7 welding table, 2000 x 1000 mm, with Ø16 mm bores on a 50 x 50 mm grid on the top and bored 100 mm sides. The top is through-hardened X8....
black Siegmund System 16 Professional Extreme 8.7 plasma nitrided welding table Steel Legs for Welding table top with holes
from $3,047.00 CAD
from $3,047.00 CAD
Item 160005.X7D: Siegmund System 16 Professional Extreme 8.7 welding table, 1000 x 500 mm, with Ø16 mm bores on a 50 x 50 mm grid on the top and bored 100 mm sides. The top is through-hardened X8.7...
Siegmund - System 16 Professional Extreme 8.7 - 1200x800x100 Plasma nitrided ‐ table side with diagonal grid Steel Legs for Welding table top with holes
from $4,311.00 CAD
from $4,311.00 CAD
Item 160025.X7D: Siegmund System 16 Professional Extreme 8.7 welding table, 1200 x 800 mm, with Ø16 mm bores on a 50 x 50 mm grid on the top and bored 100 mm sides. The top is through-hardened X8.7...
Siegmund - System 16 Professional Extreme 8.7 - 1500x1000x100 Plasma nitrided ‐ table side with diagonal grid Steel Legs for Welding table top with holes
from $5,567.00 CAD
from $5,567.00 CAD
Item 160035.X7D: Siegmund System 16 Professional Extreme 8.7 welding table, 1500 x 1000 mm, with Ø16 mm bores on a 50 x 50 mm grid on the top and bored 100 mm sides. The top is through-hardened X8....
A top view of a Siegmund System 16 Professional Extreme 8.7 Plasma Nitrided Welding Table, showcasing its checkered tabletop surface and blue-capped legs. Steel Legs for Welding table top with holes
from $7,412.00 CAD
from $7,412.00 CAD
Item 160050.X7D: Siegmund System 16 Professional Extreme 8.7 welding table, 1500 x 1500 mm, with Ø16 mm bores on a 50 x 50 mm grid on the top and bored 100 mm sides. The top is through-hardened X8....
A Siegmund System 16 Professional Extreme 8.7 welding table with a overall tabletop size 2000mm x 1200mm, featuring a grid of boreholes and reinforced with ribbing. Steel Legs for Welding table top with holes
from $8,768.00 CAD
from $8,768.00 CAD
Item 160060.X7D: Siegmund System 16 Professional Extreme 8.7 welding table, 2000 x 1200 mm, with Ø16 mm bores on a 50 x 50 mm grid on the top and bored 100 mm sides. The top is through-hardened X8....
Siegmund - System 16 Professional Extreme 8.7 - 2400x1200x100 Plasma nitrided ‐ table side with diagonal grid Steel Legs for Welding table top with holes
from $10,280.00 CAD
from $10,280.00 CAD
Item 160030.X7D: Siegmund System 16 Professional Extreme 8.7 welding table, 2400 x 1200 mm, with Ø16 mm bores on a 50 x 50 mm grid on the top and bored 100 mm sides. The top is through-hardened X8....
Siegmund - System 16 Professional Extreme 8.7 - 3000x1500x100 Plasma nitrided ‐ table side with diagonal grid Steel Legs for Welding table top with holes
from $12,830.00 CAD
from $12,830.00 CAD
Item 160040.X7D: Siegmund System 16 Professional Extreme 8.7 welding table, 3000 x 1500 mm, with Ø16 mm bores on a 50 x 50 mm grid on the top and bored 100 mm sides. The top is through-hardened X8....
big welding table canada Steel Legs for Welding table top with holes
from $21,110.00 CAD
from $21,110.00 CAD
Item 160055.X7D: Siegmund System 16 Professional Extreme 8.7 welding table, 4000 x 2000 mm, with Ø16 mm bores on a 50 x 50 mm grid on the top and bored 100 mm sides. The top is through-hardened X8....
Siegmund - System 28 Professional Extreme 8.7 - 1000x1000x200 Plasma nitrided Diagonal grid ‐ table side with diagonal grid Legs for welding table top with holes
from $6,521.00 CAD
from $6,521.00 CAD
Item 280010.XD7D: Siegmund System 28 Professional Extreme 8.7 welding table, 1000 x 1000 mm, with Ø28 mm bores in a diagonal grid on the top and bored 200 mm sides. The top is through-hardened X8.7...
Siegmund - System 28 Professional Extreme 8.7 - 1200x800x200 Plasma nitrided Diagonal grid ‐ table side with diagonal grid Legs for welding table top with holes
from $6,505.00 CAD
from $6,505.00 CAD
Item 280025.XD7D: Siegmund System 28 Professional Extreme 8.7 welding table, 1200 x 800 mm, with Ø28 mm bores in a diagonal grid on the top and bored 200 mm sides. The top is through-hardened X8.7 ...
Siegmund - System 28 Professional Extreme 8.7 - 1200x1200x200 Plasma nitrided Diagonal grid ‐ table side with diagonal grid Legs for welding table top with holes
from $8,332.00 CAD
from $8,332.00 CAD
Item 280015.XD7D: Siegmund System 28 Professional Extreme 8.7 welding table, 1200 x 1200 mm, with Ø28 mm bores in a diagonal grid on the top and bored 200 mm sides. The top is through-hardened X8.7...
Siegmund - System 28 Professional Extreme 8.7 - 1500x1000x200 Plasma nitrided Diagonal grid ‐ table side with diagonal grid Legs for welding table top with holes
from $8,960.00 CAD
from $8,960.00 CAD
Item 280035.XD7D: Siegmund System 28 Professional Extreme 8.7 welding table, 1500 x 1000 mm, with Ø28 mm bores in a diagonal grid on the top and bored 200 mm sides. The top is through-hardened X8.7...
