TC-600 Tack Clamp Pipe Clamping Tool
The Orbital Service TC-600 is a patented stainless steel pipe alignment clamp designed to simplify the positioning, securing, and tack welding of large-diameter pipe and fitting joints before final welding.
Designed for pipe outside diameters from 60 mm to 600 mm (2.36" to 23.62"), the TC-600 uses an adjustable chain-style clamping system to provide accurate fit-up across a wide range of pipe sizes without requiring multiple dedicated clamps.
Lightweight, portable, and easy to set up, the TC-600 weighs just 5 kg (11 lb) including its protective carrying case, making it an ideal solution for fabrication shops, process piping installations, and field welding applications.
Key Features & Benefits
- Patented pipe alignment clamp – Designed for accurate pipe fit-up before tack and final welding
- Wide operating range – Accommodates pipe outside diameters from 60 mm to 600 mm (2.36" to 23.62")
- Chain-style clamping system – Adapts to multiple pipe sizes using adjustable stainless steel chain links
- Ideal for pipe-to-pipe and pipe-to-fitting alignment – Helps maintain accurate joint positioning during assembly
- Lightweight and portable – Weighs just 5 kg (11 lb) including the transport case for easy handling on-site or in the shop
- Stainless steel construction – Provides excellent corrosion resistance and long service life
- Expandable design – Additional chain links can be added to accommodate larger pipe diameters when required
- Quick manual setup – Simplifies alignment with minimal training or specialized tooling
- Complete ready-to-use system – Supplied with 30 chain segments and a durable transport case
- Suitable for shop and field applications – Designed for fabrication, installation, and maintenance work
Applications
The TC-600 is designed for aligning and securing larger diameter pipe during tack welding and assembly operations.
Common applications include:
- Process piping fabrication
- Stainless steel pipe installation
- Industrial pipe welding and assembly
- Food, beverage, and pharmaceutical piping systems
- Chemical processing facilities
- Power generation and energy projects
- Water treatment and utility piping
- Field welding and maintenance operations
Its adjustable chain system allows fabricators to work with a wide variety of pipe sizes while maintaining consistent alignment before final welding.
Why Choose the Orbital Service TC-600?
Accurate pipe alignment is essential for producing high-quality welds, reducing rework, and improving fabrication efficiency, especially on larger diameter pipe.
The TC-600 provides a practical, portable solution that allows fabricators to quickly align pipe sections without the need for multiple fixed-size clamps.
Key advantages include:
- Improves pipe alignment before tack and final welding
- Reduces rework caused by joint misalignment
- Covers a wide range of pipe diameters with one clamp system
- Lightweight design for easy transport and deployment
- Durable stainless steel construction for long-term reliability
- Suitable for both workshop fabrication and field installation
Included Components
- TC-600 chain alignment clamp system
- 30 stainless steel chain segments (TC-610)
- Heavy-duty protective transport case
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | TC-600 |
| Product Type | Pipe Alignment / Tack Welding Clamp |
| Operating Range | 60–600 mm (2.36"–23.62") OD |
| Clamp System | Modular stainless steel chain links |
| Material | Stainless Steel |
| Link Calculation | External Diameter × π ÷ 65 |
| Included Links | 30 Chain Segments (TC-610) |
| Total Weight | 5 kg (11 lb) including case |
| Case Dimensions | 390 × 315 × 100 mm (15.35" × 12.40" × 3.94") |
| Application | Pipe alignment and TIG tack welding preparation |
| Transport | Supplied in heavy-duty storage case |
| Article Number | Rohrspanner60_600 |
Frequently Asked Questions
What is the Orbital Service TC-600 used for?
The TC-600 is used to align and secure large-diameter pipe and fitting joints before tack welding and final welding, helping ensure accurate fit-up and consistent weld quality.
What pipe sizes can the TC-600 accommodate?
The standard system is designed for pipe outside diameters from 60 mm to 600 mm (2.36" to 23.62").
How does the TC-600 adapt to different pipe diameters?
The clamp uses a modular chain-link design that wraps around the pipe. The adjustable chain configuration allows it to fit a wide range of pipe sizes, and additional chain links can be added for larger diameters.
Is the TC-600 suitable for field work?
Yes. Weighing just 5 kg (11 lb) including the carrying case, the TC-600 is designed for easy transport between fabrication shops and job sites.
What materials is the TC-600 made from?
The clamp is manufactured from stainless steel for excellent corrosion resistance and durability in demanding industrial environments.
What is included with the TC-600?
Each system includes the TC-600 alignment clamp, 30 stainless steel chain segments, and a heavy-duty transport case for storage and protection.
