Siegmund System 28 - Stop and Clamping Square 500 G

SKU: 2-280162.N

Siegmund

$446.00 CAD

Sale Sold out

Shipping calculated at checkout.

Quantity must be 1 or more

Item 280162.N: Siegmund Stop and Clamping Square 500 G, nitrided, for System 28 welding tables with Ø28 mm bores. It is 500 mm high, made from GGG40 ductile cast iron, and can be fixed or adjusted variably through its system bores and elongated hole; Siegmund also suggests it as a table extension. BTH Sales is the exclusive Canadian importer of Siegmund.

Specifications

Siegmund article	280162.N (siegmund.com)
System	Siegmund System 28 (Ø28 mm bores, 100 mm grid)
Length	200 mm (7.87 in)
Width	75 mm (2.95 in)
Height	500 mm (19.69 in)
Material thickness	27 mm (1.06 in)
Weight	9.4 kg (20.72 lb)
Finish	Nitrided
Stop side	Left
Material	GGG40 ductile cast iron
Scale	Fine scale, standard
Adjustment	System bores plus elongated hole (fixed or variable)
GTIN	4251805920666

Compatibility

Fits: Siegmund System 28 welding tables and tooling with Ø28 mm bores on a 100 mm grid. Siegmund System 28 accessories also fit other 28 mm system welding tables with Ø28 mm bores on a 100 mm grid. Compatible tables from other manufacturers are often made from different materials and to different standards, so quality varies by manufacturer, compared with Siegmund's X8.7 tool steel.
Siegmund System 28: fits every System 28 Siegmund table, including the Professional Extreme 8.7 and 8.8 PLUS tables listed on bthsales.ca; on a System 16 table it needs Siegmund's Reduction Bushing 28->16 (000546, suits boreholes and elongated holes) with System 16 bolts, or the Combination Fast Clamping Bolt 28->16 (000520); neither is listed on bthsales.ca.
Works with: other Siegmund System 28 clamps, bolts, stops, squares and U-squares on the same table.
Care & grounding: anti-spatter spray, CleanBasic cleaner, Ground Connection Comfort (S16/S28).

What's included

1 x Siegmund Stop and Clamping Square 500 G nitrided (280162.N)

Engineering support & demos

Engineering support comes with your purchase: fixture design, layout drawings, CAD and 3D models, site visits and cobot cell planning, handled by Travis Hardcastle at BTH Sales or by Siegmund directly. BTH Sales does not sell cobots; for cobot cells we help with table integration and fixturing (see cobot welding with Siegmund tables). Live demos at our St. Marys showroom are by appointment (book a demo), and we offer video demos if you are outside Ontario. BTH Sales is family-owned, founded in 2001, and has been the exclusive Canadian importer of Siegmund since 2018.

Typical uses

Fixed or variable stops through the system bores and elongated hole (Siegmund).
Table extension (Siegmund).
Siegmund describes System 28 as ideal for light to heavy components and designed for maximum clamping forces, multi-ton structures and high distortion forces.

Siegmund System 28 Stop and Clamping Square 500 G as a tall stop with a clamp holding an upright sheet — 500 G square as a tall stop for an upright sheet (3D render: Siegmund).

Industries served: Siegmund's published practical examples show its welding tables and tooling in these sectors: Agriculture; Interior; Lighting and electrical engineering; Machine tools and plant construction; Measurement and testing technology; Motorcycle engineering; Revolving door systems; Robotic technology; Stage technology; Stainless steel processing; Steel, sheet metal and metal construction; Textile production; Train Construction; Vehicle construction; Welding technology; Woodworking.

Frequently Asked Questions

Can the 500 G square be used as a table extension?

Yes. Siegmund says the 500 G can be fixed and variably adjusted through its system bores and elongated hole and can also be used as a table extension. It is made from GGG40 ductile cast iron.

Will it fit other 28 mm welding tables?

Yes, if the table has Ø28 mm bores on a 100 mm grid. Check the bore diameter and grid before ordering. Compatible tables from other manufacturers are often made from different materials and to different standards, so quality varies by manufacturer, compared with Siegmund's X8.7 tool steel.

Related parts

Ships across Canada from 5 Industrial Rd, St. Marys, ON N4X 1G2, or pick up from our warehouse. Email sales@bthsales.ca or call +1-519-461-1381 with questions or for a freight quote.
